• Battery Drill Winch 1000 kg

Gebuwin Battery Drill Winch 1000 kg

Product No. 77290005

Regular price $2,872.00 excl. $660.56 VAT $3,532.56 incl. $660.56 VAT
Unit price  per
Shipping calculator
Please select country
Please enter correct zip code
Payment methods
american_expressapple_paygoogle_paymaestromasterpaypalshopify_payunionpayvisa
Product details

Battery Drill Winch 1000 kg

Product information

This worm gear winch can be controlled manually with a crank or with a cordless drill, ideal in situations where there is no electrical power available but you do not want to move the load manually. This winch offers the option of using the power and speed of a cordless drill instead. The winch is also equipped with an automatic grease lubrication system and a special flexible adaptor to absorb the use and the released vibrations of the cordless drill, making it very easy to use. A very beautiful winch and a lifesaver in situations when the power fails and you still want to move the load.

Specifications

  • winch suitable for lifting and pulling in compliance with EN13157
  • static safety factor 4
  • load pressure brake with double ratchet system for safe stable hold of the load in any position
  • cable outlet upwards, downwards or at rear
  • protection classification IP54
  • automatic grease system for the worm gearing
  • adjustable crank
  • drill and hand operated
  • suitable for wall and floor mounting
  • 1 layer of paint

Available options

  • Zinc-plated finish
  • ATEX certified
  • Floor mounting
  • 2 drum compartment
  • Grooved drum
  • Pressure roller

      Technical specifications

      Capacity 1st layer

      1000 kg

      Capacity 4th layer

      725 kg

      Capacity top layer

      527 kg

      Lifting speed

      0,6 m/min

      Rope diameter-Ø

      8 mm

      Rope storage 1st layer

      5,5 meter

      Rope storage 4th layer

      29,2 meter

      Rope storage top layer

      73 meter

      Lift per crank rotation

      9 mm

      Crank effort at full load

      11 daN

      Torque ingoing shaft

      6 Nm

      Max. input rotation speed drill

      650 rpm

      Weight (without rope)

      39 kg

      Article number

      77290005
