Yale Spring Balancers YBF 0.5-200kg

Spring Balancers

Spring balancers are used to relieve the operator from the weight of hand-tools. By using a tapered rope drum the weight of the attached load is compensated, loads up to 200 kg can be moved effortlessly in a vertical axis.

Common applications are spot-welding guns, riveting machines, slaughterhouse equipment, multiple nut-runners etc.

We also supply Yale Spring Balancers with safety features in case of rope breakage.

Specifications

FEATURES

• Standard:
  - Spring balancers YBF are designed in accordance with DIN 15112
  - EC Declaration of Conformity
• Housing:
  - Manufactured from high-tensile aluminium pressure die casting for maximum resistance to impact.
• Manual Drum Lock:
  - For an easy exchange of rope or for changing the attached load.
• Spring-assembly:
  - The spring-assembly inside the balancer guarantees a consistent counterbalance throughout the complete working range.
  - As separate units in a closed steel housing for improved handling during assembly and disassembly. Reduced risk of injuries.
• Easy exchange of wire rope:
  - A small slot in the body facilitates the removal and re-installation of the rope without any need to disassemble the unit.
• Rope Guide:
  - Made of wear-resistant nylon for reduced wear of rope and body.
  - Lifetime of the spring balancer is increased.
  - The rope guide can be removed and installed on site without disassembling the rope.
• Load indicator:
  - Allows easy reading of the capacity set.
• Suspension eyes:
  - Provided for the attachment of secondary safety chains.
  - Providing additional safety and preventing the spring balancer and load from falling accidentally.
• Capacities: 0.5 - 200 kg for standard model YBF or 1.5 - 130 kg for model YBF-L (up to 300 kg available on request)
• Working Range: 1 - 1.5 m for standard model YBF or 2.3 - 2.5 m for model YBF-L
• Weight with Rope: 1 - 36 kg for standard model YBF or 3.9 - 35 kg for model YBF-L
