Yale TKR Crane Weigher with Digital Display & Radio Control

Yale TKR Crane Weigher

The Yale crane weighers TKR is compact measuring devices for the weighing of loads. The TKR model comes complete with a radio remote control. The TKL model is also available, supplied only with a standard digital display unit.

Use appropriate attachments like grade 8 forgings between the hook of the hoist or crane, the crane weigher, and the load. They are very simple and straight forward to use!

The crane weighers have a liquid crystal display (LCD), which can tare as well as show either the gross or the net load. It also indicates overload at 110% of the rated capacity and the status of the battery.

Technical Data:

• Operation time, approximately 200 hours with 4 x 1.5V AA batteries.
• Temperature range when in operation -10 C to +50 C.
• Temperature range when in storage -20 C to +70 C.
• IP 54 protection.
• 20.5mm high LCD display (4.5 digits).
• Tare range is 100% of rated capacity.
• Overload warning at 110% of the rated capacity

User Manual - Dimensions - Technical Spec

Model: TKR (WITH remote control)

The TKR crane weigher can be operated by radio control. The displayed values can be taken off the remote control device and can be easily transferred to a PC. The system can be combined with an easy-to-read display. Several measured values can be totalled and saved.

FEATURES & BENEFITS

• TKR has the same features as the TKL model plus:
• Remote control and data exchange via radio transmission.
• USB interface.
• Accumulation memory

INCLUDED IN DELIVERY OF TKR:

• Crane weigher.
• Remote control with display.
• 7 x 1.5 V AA batteries.
• Test certificate.
• PC cable.
• User software.
• Carrying case
