Pfaff Machine Lifting Jack MHS 5000-25000 kg
€844.17incl. VAT
Incl. VAT. Shipping calculated at checkout.
- 5 to 25 t capacity. Hydraulic machine jacks for lifting heavy machinery and other loads.
- Use in every position. Hand pump lifting and precision lowering valve.
- Low claw height. Claw application height from 25 mm; slewing claw on the 5 t and 10 t models.
- Easy transport. Carrying handle on the 5 t and 10 t models, carriage on the 25 t model.
- Long service life. Pressure control valve, lifting limitation and hard-chromium plated piston rod.
Capacity t:
5 Ton
Accepted payment methods
Please enter correct zip code
shipping
Pfaff MHS Machine Jack
Multi-functional lifting jacks ideal for low-height lifting or working in confined spaces. These jacks can be used in every position. Lifting is by means of a hand pump, lowering by means of a precision lowering valve. The 5000 kg and 10000 kg models have a carrying handle, the 25000 kg model has a carriage for easy movement & handling.
The 5000 kg and 10000 kg models have a slewing claw. A pressure control valve ensures a longer service life, and an integrated lifting limitation, low claw application height, large base plate and hard-chromium plated piston rod complete the design.
SPECIFICATIONS:
- Capacity: 5 - 25 t
- Stroke: 205 - 230 mm
- Min. application height with claw: 25 - 58 mm
- Weight: 25 - 109 kg
| Model | Capacity | Stroke | Min. Height (Claw) | Min. Height (Head) | Pump Lever Force | Weight |
|---|---|---|---|---|---|---|
| MHS 50 (MH 50) | 5 t | 205 mm | 25 mm | 368 mm | 38 daN | 25 kg |
| MHS 100 (MH 100) | 10 t | 230 mm | 30 mm | 420 mm | 40 daN | 35 kg |
| MHS 250 (MH 250) | 25 t | 215 mm | 58 mm | 505 mm | 40 daN | 109 kg |
