Pfaff Steel Jacks SJ 1500 - 10000 kg (DIN 7355)

Steel Jacks acc. to DIN 7355

Mechanical steel jacks can basically be used to lift almost all kinds of loads in maintenance and repair, shipbuilding, construction as well as agriculture.

They are reliable and proven equipment renowned worldwide for applications in industry, trade, and services.

In order to meet the high-quality standard, the devices are subjected to an overload test in the factory and provided with a test certificate and operating instructions with a declaration of conformity or a manufacturer’s declaration.

FEATURES

• The precisely machined gearbox with optimal gear ratio ensures a minimum of effort and smooth operation.
• The load can be positioned either on the head or the claw.
• By turning the operating lever the jack moves smoothly and conveniently up and down along the rack.
• The self-locking, anti-kickback operating lever reduces the risk of injuries. The handle can be tilted for use in confined spaces.
• The load is held securely in any position. Inside the load brake the axial brake pressure is generated by the load itself, thus, it is proportional to the size of the load.
• No reduction of capacity on the claw.

SPECIFICATIONS

• Capacity: 1500 - 10000 kg
• Height: 725 - 800mm
• Weight: 17 - 43kg
